Professional
FLOODLIGHT 65 W

FLOODLIGHT 65 W

Choose your product version

OVERVIEW

Product description Nominal wattage Number of switching cycles Beam angle Luminous flux Dimmable
FL PFM 65 W 3000 K SYM 100 BK 65.00 W 100000 100 ° x 100 ° 7150 lm No
FL PFM 65 W 4000 K SYM 100 BK 65.00 W 100000 100 ° x 100 ° 8000 lm No
FL PFM 65 W 6500 K SYM 100 BK 65.00 W 100000 100 ° x 100 ° 8000 lm No


FL PFM 65 W 3000 K SYM 100 BK

Product benefits
  • Bright, robust and durable
  • Safe and very uniform illumination, due to frosted and tempered glass diffuser
  • No upper light output ratio (ULOR 0%) when mounted at 0° tilt
  • Energy savings of up to 90 % compared to halogen lamp floodlights
  • 5 years guarantee

PRODUCT DETAILS

Electrical data

Nominal wattage 65.00 W
Nominal voltage 100…277 V
Mains frequency 50…60 Hz
Nominal current 340 mA
Inrush current 14.1 A
Inrush current time Th50 145 µs
Max. number of luminaires per miniature circuit breaker B16 29
Max. number of luminaires per miniature circuit breaker C10 21
Max. number of luminaires per miniature circuit breaker C16 33
Power factor λ > 0.90
Total harmonic distortion < 20 %
Protection class I
Operating mode Integrated LED driver

Photometrical data

Luminous flux 7150 lm
Luminous efficacy 110 lm/W
Color temperature 3000 K
Light color (designation) Warm White
Color rendering index Ra ≥80
Standard deviation of color matching ≤5 sdcm
Luminous intensity -
Flickering metric (Pst LM) -
Stroboscope effect metric (SVM) -
Photobiological safety group acc. to EN62778 RG1
Photobiological safety group acc. to EN62471 RG1
Beam angle 100 ° x 100 °

Dimensions & Weight

Length 268.00 mm
Height 49.00 mm
Width 237.00 mm
Product weight 2100.00 g
Cable length 1000 mm

Materials & Colors

Product color Black
Housing color Black
Body material Aluminum
Light emitting surface material Glass
Glow Wire Test according to IEC 60695-2-12 650 °C
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -30…+50 °C
Temperature range at storage -40…+70 °C
Type of connection Cable, 3-pole
Type of protection IP65
Protection class IK (shock resistance) IK08
Dimmable No
Mounting type Surface
Mounting location Wall, Ceiling, Floor
Application environment Outdoor
Adjustable Yes
LED module replaceable Not replaceable
With light source Yes

Lifespan

Lifespan L70/B50 at 25 °C 70000 h 1)
Lifespan L80/B10 at 25 °C 55000 h 1)
Lifespan L90/B10 at 25 °C 35000 h
Number of switching cycles 100000

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Control gear

Output current 700 mA
ECG - Output ripple current < 35 %

Certificates & Standards

Standards CE, CB, ENEC, EAC, RoHS
Luminaire with limited surface temperature, "D sign" No
Ball shot safe No
Product benefits
  • Bright, robust and durable
  • Safe and very uniform illumination, due to frosted and tempered glass diffuser
  • No upper light output ratio (ULOR 0%) when mounted at 0° tilt
  • Energy savings of up to 90 % compared to halogen lamp floodlights
  • 5 years guarantee
Areas of application
  • Replacement for floodlights with halogen lamps
  • Outdoor use (IP65)
  • Industry
  • Public areas
  • Construction areas
  • Building facades
Product features
  • Reflector-based, symmetric light distribution with 100° x 100° beam angle
  • Integrated wide voltage driver, suitable for 100 - 277 VAC
  • Surge protection: up to 6 kV (L/N-PE), 4 kV (L-N)
  • Mounting bracket with 30° angle and wide rotation area
  • Breather membrane to optimize air exchange, without compromising IP protection
  • Pre-installed, flexible 1 m cable (H05RN-F), wrapped 3 x 1.0 mm² single wires
Safety advice
  • Max. wind load surface 0.046 m²
References / Links
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075422445 Folding box
1
56 mm x 244 mm x 285 mm 2224.00 g 3.89 dm³
4058075422452 Shipping box
4
289 mm x 274 mm x 347 mm 9413.00 g 27.48 dm³
EAN SEG number STK number EFO number ELDAS number
4058075422445 7766607 4508140 3242470 941507210
