OTi DALI 80/220…240/2A1 NFC LOPTOTRONIC Intelligent

GTIN: 4062172238656 Unpacked / 1 Show all packages

Fully programmable via software (DALI Interface, NFC)
Advanced luminaire/driver data (power, energy, operating hours…) for analytics
DALI-2 certified incl. Parts 251, 252, 253
Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
High-quality dimming of 1…100 % by amplitude dimming
Higher quality of light thanks to < 3 % output ripple current
Very high efficiency
Very low standby power consumption: < 0.15 W
Fulfill safety requirement due to overload, overtemperature, Hot Plug protection

Linear lighting for office, education, industry, storage areas and retail
Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
Suitable for luminaires of protection class I

Nominal wattage	80.00 W
Nominal output power	32…80 W
Nominal voltage	220…240 V
Nominal output voltage	20…54 V
Input voltage range	220…240 V
Input voltage AC	198…264 V
Input voltage DC	176…276 V
U-OUT (working voltage)	< 60 V
Nominal output current	600…2100 mA
Inrush current	≤30 A
Output current tolerance	±3 %
Output ripple current (100 Hz)	≤ 3 %
Mains frequency	0/50/60 Hz
Total harmonic distortion	≤ 10 %
Power factor λ	≥0.95
ECG efficiency	91 % ¹⁾
Device power loss	8,0 W
Max. ECG no. on circuit breaker 10 A (C)	-
Max. ECG no. on circuit breaker 16 A (C)	-
Surge capability (L/N-Ground)	2 kV
Surge capability (L-N)	1 kV
Galvanic isolation	SELV
Flickering metric (Pst LM)	≤1

¹⁾ at 230 V, 50 Hz

Flickering metric (Pst LM)	≤1
Stroboscope effect metric (SVM)	≤0.4

Length	360 mm
Mounting hole spacing, length	350,0 mm
Width	30.00 mm
Height	21.00 mm
Cable cross-section, input side	0.5…1.5 mm²
Cable cross-section, output side	0.5…1.5 mm²
Wire preparation length, input side	8.0…9.0 mm
Wire preparation length, output side	8.0…9.0 mm
Conductor cross section	0.5…1.5 mm²
Product weight	270.00 g

Casing material	Metal
Body material	Metal

Ambient temperature range	-25…+50 °C
Maximum temperature at tc test point	75 °C
Max.housing temperature in case of fault	110 °C
Permitted rel. humidity during operation	5…85 % ¹⁾

¹⁾ Maximum 56 days/year at 85 %

ECG lifetime

100000 h, 50000 h

Dimmable	Yes
Dimming interface	DALI-2, Touch DIM, Touch DIM Sensor
Dimming range	1…100 %
Overheating protection	Automatic reversible
Overload protection	Automatic reversible
Short-circuit protection	Automatic reversible
No-load proof	Yes
Max. cable length to lamp/LED module	2,0 m ¹⁾
Suitable for fixtures with prot. class	I
Type of connection, output side	Push terminal

¹⁾ Output wires must be routed as close as possible to each other

Approval marks – approval	CE, EL, VDE-ENEC, EAC, CCC, BIS, RCM
Standards	Acc. to IEC 61347-1, Acc. to IEC 61347-2-13, Acc. to IEC 62384, Acc. to IEC 62386, Acc. to IEC 61000-3-2, Acc. to IEC 61000-3-3, Acc. to IEC 61347
Protection class	1
Type of protection	IP20

Temperature range at storage

-40…+85 °C

Networked standby power for CLS

≤0.19 W

Quantity of precious metals	0 mg
Quantity of rare earths	0 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1)
