LED DRIVER DALI Cable Clamp
DR AY ZB+DALI CLAMP
GTIN: 4058075483149
BAG / 1
Show all packages
Our warranty conditions
PRODUCT DETAILS
Product benefits
- Simple and quick cable mounting
- Sufficient space for cable connection
Areas of application
- Downlights, Panels, Linear luminaires
- Suitable for different cable types
- Suitable for indoor applications.
Product features
- Optional cable clamp for LEDVANCE Dali CC Driver
- Easy to install
- Toolless installation
Equipment / Accessories
- DR AY ZB+DALI CLAMP DUO suitable for DR DALI-26 PFM, DR DALI-44 PFM
- DR AY ZB+DALI CLAMP suitable for DR DALI-60 PFM
- DR AY DALI-P-CLAMP DUO suitable for DR DALI-P-30, DR DALI-P-42
- DR AY DALI-P-CLAMP DUO suitable for DR ZB NF P 30, DR ZB NF P 45
Dimensions & Weight
| Length | 50.0 mm |
| Width | 44 mm |
| Height | 32.0 mm |
| Product weight | 39.7 g |
Colors & materials
| Product color | Orange/White |
| Body material | Plastic |
Temperatures & operating conditions
| Maximum temperature at tc test point |
Additional product data
| Encapsulated | No |
Certificates & Standards
| Standards | Acc. to EN 61347-1, Acc. to EN 61347-2-13, Acc. to EN 55015, Acc. to EN 61547, Acc. to EN 61000-3-2, Acc. to EN 62384 |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075483149 | BAG 1 |
39.70 g | ||
| 4058075483156 | Shipping box 10 |
168 mm x 128 mm x 95 mm | 385.00 g | 2.04 dm³ |
Declarations of conformity
DR AY DALI CLAMP
DR AY DALI CLAMP
Product image: white background, spacial
DR AY ZB+DALI-CLAMP
DR AY ZB+DALI-CLAMP
Product line drawing with letters
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_ml_k.eps
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_ml_k.eps
Product line drawing with numbers
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_mn_k.eps
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_mn_k.eps
Product line drawing, front, no dimensions
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_k.eps
PG_ARF-2020-01884_DR_A Y_ZB+DALI-CLAMP_outlin e_k.eps
| EAN | SEG number | STK number | ELDAS number |
|---|---|---|---|
| 4058075483149 | 7982404 | 4031449 | 919390520 |
