LED SPECIAL T SLIM

Choose your product version

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
SPC.T SLIM 60 320 ° 6.3 W/2700 K B15d B15d 6.3 W 220…240 V 15000 h 806 lm 60 W 320 ° No
SPC.T SLIM 60 320 ° 7 W/2700 K B15d B15d 7 W 220…240 V 15000 h 806 lm 60 W 320 ° No


SPC.T SLIM 60 320 ° 6.3 W/2700 K B15d

Product benefits
  • Easy replacement of halogen lamps thanks to compact design
  • Ideal in particular for many small designer luminaires
  • Long lifetime of up to 15,000 h
  • Very low energy consumption
  • Lower thermal output (compared with the standard reference product)
  • Three year guarantee

PRODUCT DETAILS

Electrical data

Nominal wattage 6.3 W
Construction wattage 6.30 W
Nominal voltage 220…240 V
Claimed equiv. conventional lamp power 60 W
Nominal current 51 mA
Type of current AC
Inrush current 4.33 A
Operating frequency 50/60 Hz
Mains frequency 50/60 Hz
Max. lamp no. on circuit break. 10 A (B) 15
Max. lamp no. on circuit break. 16 A (B) 25
Power factor λ > 0.50

Photometrical data

Luminous intensity not applicable
Luminous flux 806 lm
Nominal useful luminous flux 90° 806 lm
Luminous efficacy 127 lm/W
Lumen main.fact.at end of nom.life time 0.70
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra ≥80
Light color 827
Standard deviation of color matching ≤6 sdcm
Rated LLMF at 6,000 h 0.80
Flickering metric (Pst LM) 1.0
Stroboscope effect metric (SVM) 0,4

Light technical data

Beam angle 320 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s
Rated beam angle (half peak value) 320.00 °

Dimensions & Weight

Overall length 90.00 mm
Diameter 18,0 mm
Maximum diameter 18 mm
Product weight 29.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C
Maximum temperature at tc test point 95 °C

Lifespan

Lifespan 15000 h
Number of switching cycles 100000
Lumen maintenance at end of serv 0.70
Rated lamp survival factor at 6,000 ≥ 0.90

Additional product data

Base (standard designation) B15d
Mercury content 0.0 mg
Mercury-free Yes
Product remark All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class A++ 1)
Energy consumption 7.00 kWh/1000h
Type of protection IP20
Standards CE, EAC
Photobiological safety group acc. to EN62778 RG1

1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)

Country-specific categorizations

Order reference LEDTSLIM60 6,3W

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional NDLS
Mains or non-mains MLS
Light source cap-type (or other electric interface) B15d
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Standby power 0 W
Networked standby power for CLS 0 W
Claim of equivalent power Yes
Length 90.00 mm
Height 18,0 mm
Width 18,0 mm
Chromaticity coordinate x 0,461
Chromaticity coordinate y 0,411
R9 Colour rendering index not applicable
Beam angle correspondence SPHERE_360
Survival factor 0,90
Displacement factor 0,5
LED light source replaces a fluorescent light source No
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075272026 Folding box
1
39 mm x 39 mm x 100 mm 34.00 g 0.15 dm³
4058075272033 Shipping box
4
96 mm x 90 mm x 109 mm 183.00 g 0.94 dm³
4058075272064 Shipping box
48
281 mm x 203 mm x 235 mm 2283.00 g 13.41 dm³
EAN SEG number STK number EFO number ELDAS number
4058075272026 8294977 4731336 3730009 941840900
Product benefits
  • Easy replacement of halogen lamps thanks to compact design
  • Ideal in particular for many small designer luminaires
  • Long lifetime of up to 15,000 h
  • Very low energy consumption
  • Lower thermal output (compared with the standard reference product)
  • Three year guarantee
Areas of application
  • Small designer luminaires
  • Luxurious living areas
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED replacement for halogen lamps with B15d base
  • Good quality of light; color rendering index Ra: ≥ 80; constant chromaticity
  • Not dimmable
Safety advice
  • To ensure full light efficiency and product lifetime, it is recommended to detach any glass or cover of the luminaire.
References / Links
  • For further products and actual information concerning LED lamps see www.ledvance.com/ledlamps
  • For Guarantee see www.ledvance.com/guarantee
