SYLVANIA Wall Sconce CCT Selectable
WALL SCONCE CCT SELECT 14W
NAED: 65570
Folding box / 1
Show all packages
Our warranty conditions
PRODUCT DETAILS
Areas of application
- Indoor applications
- Bathrooms
- Entryways & foyers
- Hallways
- Corridors
Product features
- Selectable CCTs: 2700/3000/3500/4000/5000K
- Input Voltage: 120Vac
- No warm up time, instant on with full light and consistent lamp to lamp color
- Uniform, glare free illumination distribution
- Easy installation – no additional hardware needed
- Lifetime (L70): up to 50,000 h
Equipment / Accessories
- Mounting screws and mounting brackets included
Safety advice
- cETLus, RoHS, FCC
- For indoor use only; not suitable for outdoor or wet locations
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
Electrical data
| Nominal wattage | 14.00 W |
| Nominal voltage | 120…277 V |
Photometrical data
| Luminous flux | 1150 lm |
| Luminous efficacy | 82 lm/W |
| Color temperature | 2700 … 5000 K |
| Color rendering index Ra | 90 |
Dimensions & Weight
| Length | 235.00 mm |
| Height | 267.00 mm |
| Width | 100.00 mm |
| Product weight | 776.00 g |
Materials & Colors
| Product color | White |
| Housing color | White |
| Body material | Polycarbonate (PC) |
Application & Mounting
| Dimmable | No |
| Mounting type | Surface |
| Replaceable light source | No |
Certificates & Standards
| Replaceable light source (EPREL) | Not replaceable |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 0046135655708 | Folding box 1 |
242 mm x 277 mm x 108 mm | 965.00 g | 7.24 dm³ |
| 10046135655705 | Shipping box 4 |
443 mm x 257 mm x 295 mm | 4298.00 g | 33.59 dm³ |
Extended installation guide
WALL SCONCE MANUAL
