DOWNLIGHT RETROFIT SELECTABLE
RT SELECT 1AS 5/6" 5CCT SM LM SELECT
NAED: 65736
Our warranty conditions
PRODUCT DETAILS
Areas of application
- Residential
- Bedrooms
- Kitchens
- Bathrooms
Product features
- Integrated white trim, E26 medium base socket adapter
- Selectable CCTs: 2700/3000/3500/4000/5000K
- Available in 120VAC
- Up to 100 LPW
- Energy savings up to 89 %
- Flicker-free dimming, phase-cut down to 10 %
- Color trim rings available as optional accessory
- No warm-up time, instant-on with full light output
Safety advice
- Suitable for indoor dry, damp and wet locations.
- For use in housings that can structurally support a lamp weighing one pound.
- RT5/6 designed to install in standard 5" and 6" insulated and non-insulated housings.
- Not intended for use with emergency light fixtures or exit lights.
Product Family Spec Sheet
DUAL SELECTABLE SCREW-BASE DOWNLIGHT
DUAL SELECTABLE SCREW-BASE DOWNLIGHT
Other documents / promotion
LEDVANCE Product Launch Flyer AUG 2022
LEDVANCE Product Launch Flyer AUG 2022
Other documents / promotion
LEDVANCE Performance Class Selectable Screw-Base Downlight Sales Flyer
LEDVANCE Performance Class Selectable Screw-Base Downlight Sales Flyer
Other documents / promotion
Luminaire LED Fixture and Pole Limited Warranty LEDLUM001
Luminaire LED Fixture and Pole Limited Warranty LEDLUM001
Other documents / promotion
LEDVANCE US and Canada Warranty Terms and Conditions
LEDVANCE US and Canada Warranty Terms and Conditions
Electrical data
| Nominal Wattage | 7.50/11.00/14.00 W |
| Nominal voltage | 120.00 V |
| Power factor | ≥0.90 |
| Total Harmonic Distortion | < 20 % |
Photometrical data
| Lumens | 750/1050/1300 lm |
| Efficacy | 100 lm/W |
| Color Temperature/CCT | 2700/3000/3500/4000/5000 K |
| Color Rendering Index (CRI) | 90 |
| Luminaire Type | Retrofit |
Dimensions & Weight
| Diameter | 7.36 in |
| Height | 2.8 in |
| Product weight | 0.51 lb |
Materials & Colors
| Luminaire Finish | White |
| Housing color | White |
| Housing | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
Application & Mounting
| Ambient temperature range | -20…+40 °C |
| Maximum Operating Temperature | 104 °F |
| Minimum Operating Temperature | -4 °F |
| Connectors | WAGO |
| Dimming | Yes |
| Type of Dimming | PHASE CUT |
| Mounting | Recessed |
| Replaceable light source | No |
| Holder designation | E26 |
| Primary Lamp Type | SMD |
Lifespan
| Average Rated Life (hr) | 50000 |
Certificates & Standards
| Certification Listing | RoHS; FTC; FCC; cETLus; CEC |
Additional product data
| Ordering Abbreviation | LEDRT561AS1300ST9SC3SM |
| Abbrev. With Packaging Info. | LEDRT561AS1300ST9SC3SM 4/CS 1/SKU |
| SKU UPC | 0046135657368 |
| Base | E26 Medium |
| Family Brand Name | PERFORMANCE CLASS™ |
| General Description | LED RT dual selectable screw-based, 5/6inch, 90 CRI, 5 selectable colors (2700/3000/3500/4000/5000K), 750/1050/1300 lumens, smooth reflector. T20/T24 compliant |
| Warranty | 5 years |
Logistical data
| SKU Qty | 1 |
| Case Qty | 4 |
| Case Length (in) | 13.032 |
| Case Width (in) | 8.032 |
| Case Depth (in) | 8.228 |
| Case Cube (ft) | 0.498 |
| Case Weight (lbs) | 3.237 |
| SKU UPC | 0046135657368 |
| Pallet Qty | 384 |
| SKU's/Case | 4 |
| SKU's/Pallet | 384 |
| Cases/Pallet | 96 |
