SYLVANIA 3CCT Selectable Reflectors

3CCT Selectable Reflectors BR30 8W DIM 3CCT 1PK

NAED: 41382 Folding box / 1 Show all packages
Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Areas of application
  • Downlights, pendant fixtures, table lamps, wall sconces
  • Healthcare, hospitality, residential, retail
Product features
  • Selectable CCT: 2700/3000/5000K
  • Toggle switch located on the lamp to change between CCTs in the field
  • CRI of 80 ensures good color definition
  • 15,000 hours lifetime (L70)
  • 3-year limited warranty
  • Dimmable down to 10 %
Safety advice
  • -4°F to +104°F (-20°C to +40°C)
  • Suitable for damp locations.
  • Not for use in totally enclosed fixtures.
Electrical data
Nominal wattage 8 W
Construction wattage 8.00 W
Nominal voltage 120 V
Claimed equiv. conventional lamp power 65 W
Photometrical data
Luminous flux 650 lm
Luminous efficacy 81 lm/W
Color temperature 2700 K
Color rendering index Ra 80
Light color 827
Dimensions & Weight
Overall length 130.00 mm
Diameter 95.00 mm
Product weight 67.00 g
Additional product data
Base (standard designation) E26
Mercury content 0.0 mg
Capabilities
Dimmable Yes
Country-specific categorizations
Order reference 8W 120V 6X1 EN/
Energy labelling regulation data acc EU 2019/2015
Light source cap-type (or other electric interface) E26
Correlated colour temperature type SINGLE_VALUE
Length 130.00 mm
Height 95.00 mm
Width 95.00 mm
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
0046135413827 Folding box
1		 102 mm x 114 mm x 145 mm 171.00 g 1.68 dm³
4058118229376 Shipping box
6		 330 mm x 257 mm x 161 mm 1327.00 g 13.67 dm³
