Areas of application

• Area lighting
• Shoebox
• Wall packs

Product features

• Continuous and standby dimming can be enabled on lamps 75W and higher
• For dimming, pair with the optional snap-on motion/daylight sensor and remote control
• No warm-up time, instant-on with full light output and stable color
• 180° beam angle
• Up to 150 LPW
• Energy savings up to 74 %
• Rated for open and enclosed fixtures
• 80 CRI, R9>0
• Available in 120-277V
• 6KV surge
• Easy to install, UL type B requires easy ballast bypass

Safety advice

• Verify fixture size before installation to ensure fit.
• Dimming function can only be enabled either through a physical knob on 18W-45W lamps or by pairing with a SYLVANIA motion sensor and remote control (purchased separately) for 75W-110W lamps (excluding NAED 41993).
• Dimming is not compatible with other dimmers.
• Not suited with outdoor fixtures with air vents.
• Should not be directly exposed to water.
• All installation, inspection, and maintenance of lighting fixtures should be done with the power to the fixture turned off.
• Please read and comply with all instructions, including the installation manual included inside the packaging before attempting installation.
• Lamps should be installed and operated in compliance with the National Electrical Code (NEC), Underwriters Laboratories Inc. (UL) requirements, and all applicable codes and regulations.
• See installation manual for wiring options.
• Ensure lamp holders/sockets are in good operating condition before installation and if any defects are detected, change the lamp holders/sockets.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during installation.
• Make sure the lamps have the proper connections before restoring power.
