NEW
LED Nightlight lamp
LED Superstar+ CLASSIC A60 Nightlight lamp 8W 827 FROSTED E27
GTIN: 4099854768033
개별포장박스 / 1
Show all packages
5년 보증
PRODUCT DETAILS
Product benefits
- One lamp serves both as a standard light and as a nightlight
- Gentle nightlight mode (8 lm) ensures comfortable illumination without glare
- Easily changes the light set with a double click of wall switch
Areas of application
- Wherever different lighting scenes are required: hotels, guest rooms, bedrooms, children’s rooms, nurseries
- Stairways and corridors for improved nighttime safety
- Outdoor use in suitable outdoor luminaires only
제품특징
- Dual light output modes: nightlight mode and standard mode
- Nightlight mode has soft illumination around a ring of the diffuser
- 기본 스위치를 통한 조절
Safety advice
- Do not touch the lamp if broken.
- Must not be used if outer bulb is defective.
Electrical data
| 공칭 전력 | 8 W |
| 기준 전력 | 8.00 W |
| 공칭 전압 | 220…240 V |
| 동작 방식 | AC Mains |
| 백열램프 등가 전력 | 60 W |
| 공칭 전류 | 70 mA |
| 전류타입 | 교류 |
| IP 돌입 전류 | 10.8 A |
| 동작 주파수 | 50/60 Hz |
| 일반 주파수 | 50/60 Hz |
| 회로 차단기의 최대 램프수 10 A (B) | 55 |
| Max. lamp number on MCB B16 A | 69 |
| 전고조파왜율(THD) | 123.1 % |
| 역률 λ | 0,59 |
Photometrical data
| 광속 | 806 lm |
| 광효율 | 100 lm/W |
| 수명말기 광속 유지율 | 0.96 |
| 광색 (지정) | 온백색 |
| 색온도 | 2000 K / 2700 K |
| 연색지수 Ra | 80 |
| 광색 | 820/827 |
| 배색 표준 편차 | ≤6 sdcm |
| Flickering metric (Pst LM) | 1.0 |
| Stroboscope effect metric (SVM) | 0.4 |
Light technical data
| 빔각도 | 150 ° |
| 웜업 시간 (60 %) | ‹ 0.50 s |
| 스타팅 시간 | < 0.5 s |
Dimensions & Weight
| 전장 | 114.00 mm |
| 지름 | 59,00 mm |
| 최대 직경 | 59 mm |
| 제품무게 | 45,00 g |
Temperatures & operating conditions
| 주위 온도 범위 | -20…+40 °C |
| 최대 온도(tc 테스트 포인트 시) | 100 °C |
Lifespan
| 수명 L70/B50 @ 25 °C | 25000 h |
| 점소등 주기 횟수 | 100000 |
| 램프수명말기 광속유지 | 0.96 |
Additional product data
| 베이스 (표준명칭) | E27 |
| 램프 수은함유량 | 0.0 mg |
| 무수은 | Yes |
| 디자인/버전 | 불투명 |
| 제품주석 | 전체 램프에 적용되는 모든 기술적 요소; LED 생산 과정은 복합적이기 때문에, 기술적인 LED 요소로 보여지는 대표값들은 단순히 통계적인 값으로서 각 개별 제품의 실제 기술적인 요소와 반드시 일치하지는 않으며, 대표값과 다를 수 있음 |
| Added function | Nightlight |
Capabilities
| Dimmable | No |
Certificates & Standards
| 에너지효율등급 | F 1) |
| 에너지 소비 | 8.00 kWh/1000h |
| 보호타입 | IP20 |
| 표준 | CE; EAC; UKCA |
| 광생물학적 안전그룹에 따라 EN62778 | RG1 |
1) Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)
국가별 정보
| 주문 번호 | LEDSCLA60 NIGHT |
물류 데이터
| 보관 온도 범위 | -20…+80 °C |
Energy labelling regulation data acc EU 2019/2015
| Lighting technology used | LED |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | E27 |
| Connected light source (CLS) | No |
| Color-tuneable light source | Yes |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | STEPS |
| Standby power | 0 W |
| Networked standby power for CLS | 0 W |
| Claim of equivalent power | Yes |
| 길이 | 114,00 mm |
| 높이(실린더형 등기구 포함) | 59.00 mm |
| 너비 (원형 등기구 포함) | 59.00 mm |
| Chromaticity coordinate x | 0.4578 |
| Chromaticity coordinate y | 0.4101 |
| R9 Colour rendering index | 1 |
| Beam angle correspondence | SPHERE_360 |
| Survival factor | 0.90 |
| Displacement factor | 0.93 |
| LED light source replaces a fluorescent light source | No |
| EPREL ID | 2510687 |
| Model number | AC92126 |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| 제품 코드 | 패키징 단위 (수량/단위) | 규격 (길이 x 너비 x 높이9 | Gross weight | Volume |
|---|---|---|---|---|
| 4099854768033 | 개별포장박스 1 |
60 mm x 60 mm x 155 mm | 61.00 g | 0.56 dm³ |
| 4099854768040 | 출고단위포장 6 |
208 mm x 135 mm x 130 mm | 460.00 g | 3.65 dm³ |
