| Nominal wattage | 46 W |
| Construction wattage | 46.00 W |
| Nominal wattage per LED module | 1.31 W |
| Nominal voltage | 12 V |
| Input voltage range | 12…13 V |
| Reverse Voltage | 13 V |
| Type of current | DC |
| Nominal current | 3830.000 mA |
| Total useful luminous flux [PICOS] | 5400 lm |
| Luminous efficacy | 115 lm/W |
| Luminous flux | 5580 lm |
| Luminous flux per module chain | 5400 lm |
| Color temperature | 6500 K |
| Color rendering index Ra | > 80 |
| Light color LED | White |
| Light color (designation) | Cool Daylight |
| Standard deviation of color matching | ≤3 sdcm |
| Beam angle | 155 ° |
| Rated beam angle (half peak value) | 155.00 ° |
| Number of LEDs per module | 3 |
| Number of LED modules per chain | 36 |
| Minimum operable number of LED modules | 1 |
| Length | 11100 mm |
| Width | 17.60 mm |
| Height | 7.80 mm |
| Product weight | 604.00 g |
| Ambient temperature range | -25…75 °C |
| Maximum temperature at tc test point | -25…75 °C |
| Temperature range in operation | -25…75 °C 1) |
1) At the Tc point
| Nominal lamp life time | 50000 h |
| Product remark |
Modules perfectly matched to OSRAM OPTOTRONIC® LED drivers (see relevant table), For current photometric data and important safety, installation and application information, see |
| Dimmable | Yes |
| Dimming range | 1…100 % |
| Approval marks – approval | UL recognized component, CE, ENEC |
| Standards | Acc. to ENEC 10, CE; VDE, EAC, ENEC, UL |
| Type of protection | IP66 |
| Energy consumption | 1.30 kWh/1000h |
| Energy class of contained light source | F |
| Temperature range at storage | -25…85 °C |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4052899990425 | Folding box 1 |
425 mm x 179 mm x 54 mm | 977.00 g | 4.11 dm³ |
| 4052899990432 | Shipping box 5 |
438 mm x 284 mm x 198 mm | 5185.00 g | 24.63 dm³ |
