HALOSPOT 111 PRO 50 W 12 V 24° G53

Product benefits
  • Brilliant accent lighting
  • Significantly lower CO2 emissions compared to standard version
  • Cap for reduced glare and ease of handling
  • New high-tech reflector for optimum illumination and reduced scatter
  • Approved for use in open luminaires (to IEC 60598-1)
  • UV filter
  • Drastically reduced thermal load in luminaire thanks to aluminum-coated reflector
  • Contains no mercury
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 50 W
Construction wattage 50.00 W
Nominal voltage 12 V
Claimed equiv. conventional lamp power 75 W
Nominal current 4 A
Power factor λ 1.00

Photometrical data

Luminous intensity 5500 cd
Luminous flux 650 lm
Nominal useful luminous flux 90° 650 lm
Luminous efficacy 13 lm/W
Lumen main.fact.at end of nom.life time 0.75
Light color (designation) Warm White
Color temperature 3000 K
Color rendering index Ra 100
Light color 1030
Rated peak intensity 5500 cd
UV protection Yes

Light technical data

Beam angle 24 °
Warm-up time (60 %) 0.00 s
Starting time 0.0 s

Dimensions & Weight

Overall length 58.00 mm
Diameter 111,0 mm
Maximum diameter 111 mm
Product weight 61.5 g

Lifespan

Number of switching cycles 100000

Additional product data

Base (standard designation) G53
Mercury content 0.0 mg
Mercury-free Yes
Design / version Reflector
Product remark If connectors are used, an additional holder is required at the rim of the reflector, May produce noise in combination with some dimmers. Recommended solution: use OSRAM HTi DALI 150/230-240 DIM with OSRAM DALI MCU

Capabilities

Dimmable Yes
Burning position Any

Certificates & Standards

Energy efficiency class G
Energy consumption 54.00 kWh/1000h

Country-specific categorizations

ILCOS HMGS//UBIB-50-12-G53-111/24
Order reference 48835 ES FL

Energy labelling regulation data acc EU 2019/2015

Lighting technology used OTHER
Non-directional or directional DLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) G53
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield Yes
Correlated colour temperature type SINGLE_VALUE
Length 67.00 mm
Height 111,0 mm
Width 111,0 mm
Chromaticity coordinate x 0.437
Chromaticity coordinate y 0.404
Beam angle correspondence NARROW_CONE_90
EPREL ID 1337696
Model number A349271,A349271,A349271

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Brilliant accent lighting
  • Significantly lower CO2 emissions compared to standard version
  • Cap for reduced glare and ease of handling
  • New high-tech reflector for optimum illumination and reduced scatter
  • Approved for use in open luminaires (to IEC 60598-1)
  • UV filter
  • Drastically reduced thermal load in luminaire thanks to aluminum-coated reflector
  • Contains no mercury
Areas of application
  • General illumination
  • Entrance lighting
  • Shops
  • Restaurants, hotels and similar prestigious applications
  • Offices, public buildings
Product features
  • Average life: 4,000 h
  • 100 % dimmable
  • Color rendering index Ra: 100
  • Diameter: 111 mm
  • IRC technology
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4050300656885 Folding box
1		 112 mm x 86 mm x 87 mm 89.00 g 0.84 dm³
4050300656892 Shipping box
6		 275 mm x 130 mm x 185 mm 663.00 g 6.61 dm³
