LED PERFORMANCE PANEL HE Backlit

LED PERFORMANCE PANEL 0312 28W 3000K

GTIN: 4058075727205 Folding box / 1 Show all packages
Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Product benefits
  • Sturdy SPCC housing
  • Safety compliance certificates: CB, EU RoHS 2.0
  • Low maintenance costs thanks to long lifetime
  • Seamless aluminum frame design
  • IP54 protection from diffuser side suitable for different installations (0606 models)
  • High system efficacy 143 lm/W reduce energy consumption (4000K & 6500K)
Areas of application
  • Offices
  • Retail and small shops
  • Hospitals
  • Public areas
Product features
  • Latest backlit LED technology platform
  • Available in standard 600 x 600 mm, 300 x 1200 mm size
  • Standard CCT: 4000 K & 6500 K, 3000 K on request
  • Color rendering index Ra: > 80
  • Power factor: > 0.9
  • Recess mount with optional plaster ceiling mounting clips and suspension kit
  • 100-277 V wide voltage operation models available
  • SASO 2902 Energy Efficiency Class A certified (0606 WV)
  • Integrated heat resistance lens for uniform light distribution, reduce product height to only 34 mm
Electrical data
Nominal wattage 28.00 W
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Nominal current 160.000 mA
Max. number of luminaires per miniature circuit breaker B16 24
Max. number of luminaires per miniature circuit breaker C10 23
Max. number of luminaires per miniature circuit breaker C16 37
Power factor λ 0.90
Total harmonic distortion ≤ 15 %
Protection class II
Photometrical data
Luminous flux 3680 lm
Luminous efficacy 131 lm/W
Color temperature 3000 K
Light color (designation) Warm White
Color rendering index Ra > 80
Standard deviation of color matching < 5 sdcm
Photobiological safety group acc. to EN62778 RG0
UGR < 22
Dimensions & Weight
Length 1195.00 mm
Height 34.00 mm
Width 295.00 mm
Product weight 1630.00 g
Materials & Colors
Product color White
Housing color White
Body material Steel
Glow Wire Test according to IEC 60695-2-12 650 °C
Mercury content 0.0 mg
Application & Mounting
Ambient temperature range -10…+50 °C
Temperature range at storage -20…+70 °C
Type of connection Terminal, 2-Pole (L, N)
Type of protection IP40~IP20
Protection class IK (shock resistance) IK02
Dimmable No
Mounting type Recessed
Application environment Indoor
Mounting length 1195.0 mm
Mounting width 295,0 mm
Replaceable light source No
Lifespan
Lifespan L70/B50 at 25 °C 50000 h 1)
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Certificates & Standards
Standards CB
Replaceable light source (EPREL) Not replaceable
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075727205 Folding box
1		 1,203 mm x 40 mm x 341 mm 2004.00 g 16.41 dm³
4058075727212 Shipping box
5		 1,258 mm x 223 mm x 408 mm 11022.00 g 114.46 dm³
Product image: white background, diagonal
LDPFM PL0312B 28W
JPG (799.45 KB)
Product line drawing with numbers
LDPFM PL0312B 28W
PNG (11.07 KB)
IES file (IES)
LDPFM PL0312B 28W 830 H
IES (5.02 KB)
