LINEAR HIGH OUTPUT GEN 2

LDPFM LN HO 1500 70W TRI8

GTIN: 4099854528736 Folding box / 1 Show all packages
Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Product benefits
  • Replacement of conventional T8 tubes with up to 7500 lm (1.2 m version) and up to 10500 lm (1.5 m version)
  • Energy savings up to 70 % (compared to luminaires that use fluorescent lamps)
  • Robust structure with IK08
  • Easy installation and versatile application
  • 5 years guarantee
Electrical data
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Photometrical data
Color temperature 3000 K / 4000 K / 6500 K
Color rendering index Ra > 80
Beam angle 120 °
Dimensions & Weight
Length 1458.00 mm
Height 74.00 mm
Width 65.00 mm
Product weight 1410.00 g
Materials & Colors
Body material Metal|Steel
Application & Mounting
Type of protection IP20
Dimmable No
Replaceable light source No
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4099854528736 Folding box
1		 69 mm x 1,464 mm x 77 mm 1510.00 g 7.78 dm³
4099854528743 Shipping box
6		 1,474 mm x 225 mm x 170 mm 9810.00 g 56.38 dm³
