LDPFM DP 600 16W 840 S G4

GTIN: 4099854360251 Folding box / 1 Show all packages

UV-stabilized polycarbonate opal diffuser ensures uniform light distribution and long-lasting durability
Polycarbonate body and diffuser offers IK08 impact protection
Sleek and lightweight slim body design, compact but powerful
Long 50,000 hours lifetime reduces maintenance costs
Sensor design with more energy saving

Available in 7 wattages and lumen packages
Available in 3 length options, ensuring direct replacement of traditional 2-4-5 feet fluorescent dampproof fixtures
Input voltage: 220…240 V
Operating frequency: 50/60 Hz
High system lumen efficacy: up to 150 lm/W
Color rendering index R_a: > 80
High frequency sensor for daylight and motion detection
Anti-corrosion stainless steel clips
Type of protection: IP66
Impact resistance: IK08
Class I Luminaires
CB, EMC, RED, RoHS certified

Nominal wattage	16.00 W
Nominal voltage	220…240 V
Mains frequency	50…60 Hz
Nominal current	75.000 mA
Inrush current	6.5 A
Max. number of luminaires per miniature circuit breaker B16	16
Max. number of luminaires per miniature circuit breaker C10	13
Max. number of luminaires per miniature circuit breaker C16	21
Power factor λ	0.90
Total harmonic distortion	≤ 15 %
Protection class	I
Surge capability (L/N-Ground)	2 kV
Operating mode	Integrated LED driver

Luminous flux	2400 lm
Luminous efficacy	150 lm/W
Color temperature	4000 K
Light color (designation)	Cool White
Color rendering index Ra	> 80
Standard deviation of color matching	< 5 sdcm
Flickering metric (Pst LM)	≤ 1
Stroboscope effect metric (SVM)	≤ 0.4
Photobiological safety group acc. to EN62778	RG0
Beam angle	120 °

Product color	Gray
Housing color	Gray
Body material	Plastic
Cover material	Polycarbonate (PC)
Light emitting surface material	Polycarbonate (PC)
Mercury content	0.0 mg

Ambient temperature range	-20…+50 °C
Temperature range at storage	-20…+80 °C
Type of connection	Terminal, 5-pin
Type of protection	IP66
Protection class IK (shock resistance)	IK08
Dimmable	No
Mounting type	Surface/Suspended
Application environment	Indoor
With light source	Yes
Replaceable light source	No

Lifespan L70/B50 at 25 °C	50000 h ¹⁾
Number of switching cycles	25000

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta)

Output current

110 mA

Type of sensor	Motion, Light
Sensor detection angle	‹ 140 °
Sensor controlled switching time	30 s…60 s
Detection range of motion sensor	0.5…5 m
Detection threshold of daylight sensor	25 lx

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	No
