DP HE EL 1500 P 40W ML 840 IP65

NEW

DAMP PROOF HIGH EFFICIENCY EMERGENCY

GTIN: 4099854407079 Folding box / 1 Show all packages

Download data sheet

Contact sales

Our warranty conditions

Tools

Fast Light Calculation Tool
The fast way to plan lighting projects

PRODUCT DETAILS

Product benefits

Seamless integration of luminaires with emergency lighting function into general lighting
Easy wiring thanks to included prewired driver and battery for Emergency lighting function
Simple testing of luminaires with emergency lighting function thanks to integrated automatic test function
Convenient visualization of results of automatic test with an included control LED
Operation of integrated emergency lighting function with long life LiFePO4 battery with 3h battery discharge time
Uniform light distribution
Enables participation in funding programs in certain countries to replace light source and driver
Easy installation, no tools required for connection
Energy savings up to 68 % (compared to luminaires that use fluorescent lamps)

Areas of application

Emergency illumination of escape routes
Antipanic lighting
Buildings requiring up to 3 h emergency light operation
Industrial and storage facilities
Workshops, assembly lines
Passages, underpasses
Parking garages
Underground parking

Product features

Luminaire suited for normal lighting and emergency lighting
Certified according to European norms (EN 60598-1:2020; EN 60598-2-22:2021)
Self-contained luminaires
Luminous flux in emergency operation mode: 450 lm
Emergency lighting function: battery discharge time of 3 h
Function test of emergency lighting: automatic (AT)
Battery technology: LiFePO4
Housing and diffuser material: polycarbonate (PC)
Multi Lumen function: power steps selectable
Compatible to Zhaga Book 26 LED light sources
Beam angle: 120°
Protection rating: IP65

Equipment / Accessories

Mounting brackets, Antitheft protection, triangle, 2nd cable gland and 2 grommets included
EVERLOOP luminaire: upgrades and replacements available

Safety advice

All electrical connections must be made by a qualified person.
Caution, risk of electric shock.
Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.

References / Links

For Guarantee see www.ledvance.com/guarantee

Electrical data

Nominal wattage	39.8 W / 35.6 W / 31.7 W / 27.5 W / 24.0 W / 20.6 W / 16.6 W
Nominal voltage	220…240 V
Mains frequency	50/60 Hz
Nominal current	175/165/150/130/115/100/85 mA
Inrush current	9.8 A
Inrush current time T_h50	565 µs
Max. number of luminaires per miniature circuit breaker B16	14
Max. number of luminaires per miniature circuit breaker C10	15
Max. number of luminaires per miniature circuit breaker C16	25
Power factor λ	> 0.90
Total harmonic distortion	< 15 %
Protection class	I
Operating mode	Integrated LED driver

Photometrical data

Luminous flux	6400 lm / 5700 lm / 5070 lm / 4360 lm / 3810 lm / 3240 lm / 2590 lm
Luminous efficacy	161 lm/W / 160 lm/W / 159 lm/W / 157 lm/W / 156 lm/W
Color temperature	4000 K
Light color (designation)	Cool White
Color rendering index Ra	≥80
Standard deviation of color matching	< 4 sdcm
Low flicker	Yes
Flickering metric (Pst LM)	< 1
Stroboscope effect metric (SVM)	< 0.4
Photobiological safety group acc. to EN62778	RG1
Beam angle	120 °

Adjustable attributes

Nominal wattage	Color temperature	Luminous flux	Luminous efficacy
39.8 W	4000 K	6400 lm	161 lm/W
35.6 W	4000 K	5700 lm	160 lm/W
31.7 W	4000 K	5070 lm	160 lm/W
27.5 W	4000 K	4360 lm	159 lm/W
24.0 W	4000 K	3810 lm	159 lm/W
20.6 W	4000 K	3240 lm	157 lm/W
16.6 W	4000 K	2590 lm	156 lm/W

Dimensions & Weight

Length	1500.00 mm
Height	68.00 mm
Width	82.00 mm
Product weight	1930.00 g

Materials & Colors

Product color	Gray
Housing color	Gray
Body material	Polycarbonate (PC)
Cover material	Polycarbonate (PC)
Light emitting surface material	Polycarbonate (PC)
Glow Wire Test according to IEC 60695-2-12	850 °C
Mercury content	0.0 mg

Application & Mounting

Ambient temperature range	+5…+35 °C
Temperature range at storage	-20…+80 °C
Type of connection	Screwless terminal, 5-Pole
Type of protection	IP65
Protection class IK (shock resistance)	IK08
Dimmable	No
Mounting type	Suspended/Surface
Mounting location	Ceiling
Application environment	Indoor
With light source	Yes
Replaceable light source	Yes

Lifespan

Lifespan L70/B50 at 25 °C	100000 h ¹⁾
Lifespan L80/B10 at 25 °C	100000 h ¹⁾
Lifespan L90/B10 at 25 °C	59000 h
Number of switching cycles	100000

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Control gear

Output current	250 mA
ECG - Output ripple current	< 5 %

BATTERY

Type of Battery	LiFePO4
Battery size [GMS]	Others
Nominal voltage of battery	3.2 V
Nominal capacity of battery	6000 mAh
Battery charging time	24 h

Emergency lighting

Type of Emergency Lighting (EL)	EL unit (battery and controller) for decentral operation included
Area of emergency application	Anti-panic lighting, Escape route lighting
Type of emergency light operation	Maintained, Non-maintained
Type of emergency operation test	Automatic
Wattage in maintained operation mode	40 W
Wattage in emergency operation mode	3 W
Luminous flux in maintained operation mode	6400 lm
Luminous flux in emergency operation mode	450 lm
Battery life in emergency operation mode	3 h

Certificates & Standards

Standards	CE, CB, ENEC, UKCA, EAC
Luminaire with limited surface temperature, "D sign"	Yes
Ball shot safe	No
Replaceable light source (EPREL)	Only by an expert

Additional product data

Added function

EVERLOOP, MULTI SELECT

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1), 2-(2H-benzotriazol-2-yl)-4-(1,1,3,3-tetramethylbutyl)phenol (3147-75-9)
